Product Overview
The SUS2050SB is a small-roller double-pitch stainless steel sprocket for No.2050S SS chain at 31.75 mm pitch. Stepping up in pitch from the 2040 series, this sprocket handles moderate conveying loads that exceed the capacity of smaller-pitch double-pitch drives while retaining the low-noise, low-inertia advantages that make double-pitch drives popular in food processing, logistics, and packaging machinery.
Available in effective tooth counts of 9½ through 12½, the SUS2050SB is a direct-fit replacement for Tsubaki 2050S, Iwis DP50 stainless, and equivalent Renold double-pitch 50-series components — manufactured in our Hangzhou CNC facility and priced factory-direct, removing the distribution chain that adds cost when sourcing equivalent European or Japanese parts.
Dimensional Specifications — SUS2050SB
Full dimensional data for all standard configurations. Effective tooth count reflects the number of rollers engaged per revolution. Hub bore, hub dimensions, and weight are listed for each size.
| Sprocket No. | Eff. Teeth | Outside Dia. (mm) | Pitch Dia. (mm) | Stock Bore (mm) | Min Bore (mm) | Max Bore (mm) | Hub BD (mm) | Hub BL (mm) | Weight (kg) |
|---|---|---|---|---|---|---|---|---|---|
| SUS2050SB | 9½ | 105 | 97.78 | 14.5 | 16.5 | 48 | 73 | 28 | 1.10 |
| SUS2050SB | 10½ | 115 | 107.72 | 14.5 | 16.5 | 48 | 73 | 28 | 1.62 |
| SUS2050SB | 11½ | 125 | 117.68 | 16 | 18 | 48 | 73 | 28 | 1.74 |
| SUS2050SB | 12½ | 135 | 127.67 | 16 | 18 | 48 | 73 | 28 | 1.87 |
Why Double-Pitch at 31.75 mm?
The 31.75 mm (1.25 inch) pitch of No.2050 double-pitch chain places this product firmly in the medium-duty conveying category. Applications include supermarket checkout conveyors, tote-bin transport systems, poultry and fish-processing lines, and bottling-plant conveyors — all of which need enough chain strength to handle real product weights, but benefit from the quieter, lighter chain-and-sprocket combination that double-pitch provides over standard No.50 chain at the same conveying speed.
The small-roller design of the SUS2050SB means the chain rollers are the same diameter as the standard No.50 chain roller (10.16 mm), maintaining compatibility with standard chain guides and wear strips that may already be fitted to the machine. This makes the SUS2050SB a practical retrofit choice when converting a machine from standard-pitch to double-pitch to reduce noise or drive-motor load.
Performance & Material Characteristics
Matching Components & Related Parts We Supply
The SUS2050SB is one component in a complete double-pitch stainless drive. The items below are stocked and available for consolidated shipment.
What Our Customers Say
“Replaced Tsubaki 2050S sprockets on our fish-conveyor line with SUS2050SB. Identical dimensions, better price, 8 days delivery. The stainless finish holds up perfectly to our daily steam cleaning.”
“We switched to Ever-Power for our double-pitch sprocket supply after trialling three pieces. Quality is consistent across batches, which matters a lot for our MRO programme.”
“Good product, tooth form matches the Renold originals we checked against. One point off because the packaging scratched one sprocket face in transit — not a functional issue but noted for the next order.”
Lead Times & How to Order
Stock-bore SUS2050SB units ship in 3–6 business days. Custom bore and keyway orders require 8–12 business days after drawing confirmation. MOQ: 1 piece (stock), 10 pieces (custom). Contact us for blanket-order pricing on annual supply programmes.
Tell us your effective tooth count, bore diameter, and required quantity — quote back within 24 hours.
