Description
Product Overview
The SUS2040RB is a large-roller double-pitch stainless steel sprocket designed for No.2040R SS (also known as No.2042 SS) roller chain. The critical distinction from the SUS2040SB is the roller diameter: where the SB uses a 7.95 mm small roller identical to standard No.40 chain, the RB uses a 15.88 mm large roller — the same diameter as No.80 chain. This large roller enables the chain to ride on flat or curved conveyor tracks and curved guide rails, making the 2040R / 2042 combination the standard choice for overhead power-and-free conveyor systems and track-guided product carriers.
Machined in 304-grade stainless steel at our Hangzhou plant, SUS2040RB covers 10 through 13 effective teeth and replaces Tsubaki 2042 stainless, Renold 2040R double-pitch, and Rexnord 2042-series components with factory-direct pricing and short custom-bore lead times.
SB vs RB — Understanding the Difference
| Parameter | SUS2040SB (Small Roller) | SUS2040RB (Large Roller) |
|---|---|---|
| Roller Dia. | 7.95 mm (same as No.40) | 15.88 mm (same as No.80) |
| Chain type | No.2040S / 2040 SS | No.2040R / 2042 SS |
| Track running | Standard V-guide only | Flat rail & curved track supported |
| Typical use | Standard conveyor drives | Overhead monorail, power-and-free systems |
| Interchangeable? | No — different roller diameter | No — different roller diameter |
Chain Parameters & Dimensional Specifications
Dimensional data for all standard SUS2040RB configurations. Custom tooth counts and bore sizes are available on request.
| Eff. Teeth | Outside Dia. (mm) | Pitch Dia. (mm) | Stock Bore (mm) | Min Bore (mm) | Max Bore (mm) | Hub BD (mm) | Hub BL (mm) | Weight (kg) |
|---|---|---|---|---|---|---|---|---|
| 10 | 93 | 82.20 | 12.5 | 14.5 | 42 | 63 | 25 | — |
| 11 | 102 | 90.16 | 12.5 | 14.5 | 42 | 63 | 25 | — |
| 12 | 108 | 98.14 | 12.5 | 14.5 | 42 | 63 | 25 | — |
| 13 | 118 | 106.14 | 12.5 | 14.5 | 42 | 63 | 25 | — |
Key Features
Applications
The large-roller 2040R / 2042 combination is the industry standard for a specific class of conveyor: systems where the chain must also serve as a running surface or guide element. Common deployments include overhead power-and-free trolley conveyors in automotive plants, electrified monorail systems in distribution facilities, and clean-room overhead product carriers in pharmaceutical manufacturing.
Matching Components & Related Parts We Supply
We supply everything needed for a complete No.2040R stainless drive.
What Our Customers Say
“SUS2040RB replaces our Tsubaki 2042 sprockets on an overhead monorail in our cheese-production facility. Perfect dimensional match, and the stainless holds up to our twice-daily wash-down with no issues. Highly recommended.”
“Ordered 8 pieces with 42 mm bore. Arrived dimensionally correct, keyway matched our shaft keys. The overseas lead time (10 days) was faster than getting parts through our local Tsubaki distributor. Will continue sourcing from Ever-Power.”
“Good quality and clear communication from the sales team. Minor cosmetic mark on one piece from transit packaging — flagged it and they offered a credit on the next order. Good after-sales attitude.”
Contact us with your SUS2040RB tooth count, bore, and quantity — we quote within 24 hours.
